Tooltos 4-in-1 Manual Jewelry Rolling Mill | Flat Round Square Half-Round Wire 0.1-7mm
- 94 in stock
Description
- 4-in-1 Rolling Capability — Flat sheet, round wire, square wire and half-round wire profiles in one machine. The most versatile manual rolling mill in the Tooltos range.
- 0.1–7mm Thickness Range — Wide opening accommodates thicker starting stock and fine gauge reduction down to 0.1mm.
- 1:2.5 Gear Ratio — One roller turn per 2.5 handle turns, reducing the force required for each rolling pass.
- Cast Iron Frame and Forged Chrome Steel Rollers — Heavy-duty construction with blue powder-coat finish for rigidity, corrosion resistance and long service life.
- Sheet Capacity up to 40mm Wide — Suitable for bangles, cuffs and flat stock preparation.
The Tooltos 4-in-1 Manual Jewelry Rolling Mill handles flat sheet, round wire, square wire and half-round wire in a single cast iron frame — the most complete wire and sheet rolling capability in the Tooltos manual rolling mill range. The 1:2.5 gear ratio reduces hand force for each pass, and the 0.1–7mm opening accommodates thicker starting stock than standard 4–4.5mm models. Suitable for goldsmiths, silversmiths, jewelry students and studio bench jewelers working with gold, silver, copper, brass and other non-ferrous metals.
Best For / Not For
| Best For | Not For |
|---|---|
| Flat sheet rolling and thinning (up to 40mm wide) Round wire gauge reduction Square wire forming Half-round wire forming Texture transfer to sheet metal Gold, silver, copper, brass, bronze Jewelry studios, goldsmiths and silversmiths |
Steel or hardened metals (will damage rollers) Sheet wider than 40mm High-volume continuous production (choose electric mill) Use without secure workbench mounting |
Tooltos Manual Rolling Mill Comparison
| Feature | 4-in-1 (This) | 3-in-1 110mm | 2-in-1 112mm |
|---|---|---|---|
| Wire Profiles | Round + Square + Half-Round | Square + Half-Round | Half-Round only |
| Max Opening | 7mm | 4mm | 7mm |
| Gear Ratio | 1:2.5 | 4:1 | 1:2.5 |
| Sheet Width | 40mm | 53mm | 112mm |
| Best For | Most wire profiles, versatile forming | Standard studio, easier handle effort | Wide sheet, thicker stock |
Technical Specifications
| Gear Ratio | 1:2.5 |
| Thickness Range | 0.1–7mm |
| Sheet Capacity | 1–40mm wide |
| Round Wire Profiles | 2 / 2.5 / 3.5 / 4.5 / 5.5 / 6.5mm |
| Square Wire Profiles | 1 / 1.5 / 2.5 / 3 / 4 / 5 / 6mm |
| Half-Round Wire Profiles | 2 / 2.5 / 3 / 3.5 / 4.5 / 5 / 7.5 / 9 / 10mm |
| Frame Material | Cast Iron with Blue Powder Coating |
| Roller Material | Forged Chrome Steel |
| Machine Dimensions | 345 × 135 × 295mm / 13.6 × 5.3 × 11.6 in |
| Machine Weight | 17.28 kg / 38.1 lb |
| Operation | Manual (hand-operated, no power required) |
| Suitable Metals | Gold, silver, copper, brass, bronze and other non-ferrous metals |
Workshop Applications
| Application | Description |
|---|---|
| Sheet Metal Reduction | Reduce gold, silver or copper sheet to precise gauge for rings, pendants and earrings |
| Round Wire Drawing | Reduce round wire diameter across 6 profile sizes from 2mm to 6.5mm |
| Square Wire Forming | Form square wire profiles in 7 sizes from 1mm to 6mm for rings and settings |
| Half-Round Wire Forming | Form half-round wire in 9 sizes from 2mm to 10mm for bezels and decorative work |
| Texture Transfer | Roll textures and patterns into sheet metal using the flat rollers |
Pro Tips
- Anneal metal before rolling to reduce cracking and make each pass easier on the rollers.
- Reduce thickness by 10–15% per pass for best surface quality and longer roller life.
- Keep rollers clean and lightly oiled to prevent surface marks on your metal.
- Mount the machine securely to a sturdy bench before use — the mounting holes allow fixed installation for stable, accurate rolling.
- For texture transfer, place annealed metal and a texture sheet between the flat rollers and make a single slow pass.
Frequently Asked Questions
What metals can this rolling mill handle?
Gold, silver, copper, brass and bronze. Not recommended for hardened steel or titanium — these will damage the rollers.
What is the difference between this and the 3-in-1 models?
This 4-in-1 model adds round wire rolling to the flat sheet, square wire and half-round wire capability of the 3-in-1 models. It is the most versatile manual rolling mill in the Tooltos range for wire forming.
Does it need to be bolted to a bench?
Yes. The 17.28kg frame must be securely mounted to a stable workbench before use for safe and accurate rolling.
Can I use it for texture pressing?
Yes. Place annealed metal and a texture sheet between the flat rollers and make a single slow pass to transfer the pattern.
Is there a motor option?
No. This is a manual hand-crank mill. The 1:2.5 gear ratio makes hand rolling practical for jewelry-scale stock.
What is the maximum sheet width I can roll?
Up to 40mm wide. For wider sheet work, the 112mm 2-in-1 model supports up to 112mm sheet width.
Should I anneal between passes?
Yes. Annealing work-hardened metal between passes prevents cracking and makes rolling easier, especially for multiple thickness reductions.
What's Included
- 1 x Tooltos 4-in-1 Manual Jewelry Rolling Mill Machine
- Mounting hardware included
